NEW 250 DV: 10" Manual, Pivot-Style Cold Saw (2-3/4" Round Tube Capacity)
Ready to place an order, or do you have any questions?
Call us at (704) 703-9400
The Quantum Macc NEW 250 DV Manual Cold Saw has the capability of mitering the head up to 45° Degrees Left and up to 45° Degrees Right. The reduction unit is in an oil bath with a Membrane Pump for the coolant and coolant filter. The NEW 250 DV is equipped with a Dual-Vice and Bar Stop. Service tools come with the machine, as well as the machine's manual and Steel Pedestal / Base.
Ready to place an order, or do you have any questions?
Call us at (704) 703-9400
The Quantum Macc NEW 250 DV Manual Cold Saw has the capability of mitering the head up to 45° Degrees Left and up to 45° Degrees Right. The reduction unit is in an oil bath with a Membrane Pump for the coolant and coolant filter. The NEW 250 DV is equipped with a Dual-Vice and Bar Stop. Service tools come with the machine, as well as the machine's manual and Steel Pedestal / Base.
Ready to place an order, or do you have any questions?
Call us at (704) 703-9400
The Quantum Macc NEW 250 DV Manual Cold Saw has the capability of mitering the head up to 45° Degrees Left and up to 45° Degrees Right. The reduction unit is in an oil bath with a Membrane Pump for the coolant and coolant filter. The NEW 250 DV is equipped with a Dual-Vice and Bar Stop. Service tools come with the machine, as well as the machine's manual and Steel Pedestal / Base.
NEW 250 DV COLD SAW CUTTING CAPACITIES:
Round Tube Cutting Capacities:
Round Tube Cutting at 90° (Straight Cut): 2-3/4"
Round Tube Cutting at 45° Right: 2-1/2"
Round Tube Cutting at 45° Left: 2-1/2"
Square Tube Cutting Capacities:
Square Tube Cutting at 90° (Straight Cut): 2-3/4"
Square Tube Cutting at 45° Right: 2-1/4"
Square Tube Cutting at 45° Left: 2-1/4"
Solid Round Cutting Capacities:
Solid Round Cutting at 90° (Straight Cut): 1-1/2"
Solid Round Cutting at 45° Right: 1-3/8"
Solid Round Cutting at 45° Left: 1-3/8"
Rectangular Tube Cutting Capacities:
Rectangular Tube Cutting at 90° (Straight Cut): 2-1/8" x 3-3/4"
Rectangular Tube Cutting at 45° Right: 2-1/8" x 2-1/2"
Rectangular Tube Cutting at 45° Left: 2-1/8" x 2-1/2”
NEW 250 DV COLD SAW SPECIFICATIONS:
— Blade Size Used: 250 x 2 x 32mm Bore HSS Blade
— 2 Speeds: 40 & 80 R.P.M.
— Weight: 207 lbs. (94 kg.)
— Maximum Vice Opening: 3.9” (100mm)
— Overall Dimensions: 32” Height x 33” Length x 30” Width (800 x 830 x 755 mm)
— 2 Speeds: 40 - 80 R.P.M.
— Weight: 207 lbs. (94 kg.)
— Maximum Vice Opening: 3.9” (100mm)
— Overall Dimensions: 32” Height x 33” Length x 30” Width (800 x 830 x 755mm)
