NTA 370: 14.50" Fully-Automatic, Double-Column Cold Saw
INCLUDES VARIABLE SPEED INVERTER AND 1 BLADE
READY TO PLACE AN ORDER, OR DO YOU HAVE ANY QUESTIONS?
CALL US AT (704) 703-9400
The Quantum Macc NTA 370 Vertical Double-Column Fully-Automatic Cold Saw has a moveable head that can move up to 45 degrees right and left; and the head also has rotation stops at 45° - 0° - 45°. The NTA 370 has a vice that is complete with an anti-burr device, and a motor pump for blade lubrication. This unit is equipped with a bar stop, bar support arm, and service tools, as well as the machine's manual. The NTA 370 can store up to 9 programs, each of them with 99 steps for a total of about 890 cutting positions with relevant piece-counter.
INCLUDES VARIABLE SPEED INVERTER AND 1 BLADE
READY TO PLACE AN ORDER, OR DO YOU HAVE ANY QUESTIONS?
CALL US AT (704) 703-9400
The Quantum Macc NTA 370 Vertical Double-Column Fully-Automatic Cold Saw has a moveable head that can move up to 45 degrees right and left; and the head also has rotation stops at 45° - 0° - 45°. The NTA 370 has a vice that is complete with an anti-burr device, and a motor pump for blade lubrication. This unit is equipped with a bar stop, bar support arm, and service tools, as well as the machine's manual. The NTA 370 can store up to 9 programs, each of them with 99 steps for a total of about 890 cutting positions with relevant piece-counter.
INCLUDES VARIABLE SPEED INVERTER AND 1 BLADE
READY TO PLACE AN ORDER, OR DO YOU HAVE ANY QUESTIONS?
CALL US AT (704) 703-9400
The Quantum Macc NTA 370 Vertical Double-Column Fully-Automatic Cold Saw has a moveable head that can move up to 45 degrees right and left; and the head also has rotation stops at 45° - 0° - 45°. The NTA 370 has a vice that is complete with an anti-burr device, and a motor pump for blade lubrication. This unit is equipped with a bar stop, bar support arm, and service tools, as well as the machine's manual. The NTA 370 can store up to 9 programs, each of them with 99 steps for a total of about 890 cutting positions with relevant piece-counter.
NTA 370 COLD SAW CUTTING CAPACITIES:
Round Tube Cutting Capacities:
Round Tube Cutting at 90° (Straight Cut): 3"
Round Tube Cutting at 45° Left: 3"
Round Tube Cutting at 45° Right: 3"
Square Tube Cutting Capacities:
Square Tube Cutting at 90° (Straight Cut): 3"
Square Tube Cutting at 45° Left: 3"
Square Tube Cutting at 45° Right: 3"
Solid Round Cutting Capacities:
Solid Round Cutting at 90° (Straight Cut): 3"
Solid Round Cutting at 45° Left: 3"
Solid Round Cutting at 45° Right: 3"
Rectangular Tube Cutting Capacities:
Rectangular Tube Cutting at 90° (Straight Cut): 3-7/8" x 3"
Rectangular Tube Cutting at 45° Left: 3-7/8" x 3"
Rectangular Tube Cutting at 45° Right: 3-7/8" x 3"
NTA 370 COLD SAW SPECIFICATIONS:
— Blade Size Used: 370 x 2.5 x 32mm Bore HSS Blade
— 2 Speeds: 25 & 50 R.P.M.
— Weight: 1,985 lbs. (900 kg.)
— Maximum Vice Opening: 7.2” (185mm)
— Step Feeder Stroke Length: 23.60”
— Overall Dimensions: 138” Width x 48” Length x 75” Height (3500 x 1200 x 1900 mm)
— The NTA 370 can store up to 9 programs, each of them with 99 steps for a total of about 890 cutting positions with relevant piece-counter.
— Tempered and ground vertical slider along with Tempered and ground vice jaws
— Head lowering adjustment.
— Equipped with the Shave breaker and Vice complete with Anti-Burr Device.
Cycle start is obtained by pressing the relevant start pedal. The machine performs the following operations during the cutting cycle:
Feeding of Material.
Closing of Vice and Fixed Vice will Lock.
Activation of Blade Motor, Rotation of the Blade and Delivery of Coolant.
Cutting Head Begins Down-Stroke. (While the head is descending to make the cut, the Feeding Carriage will return to the fixed measure - preparing itself for the next step of feeding the material).
Completes Cut & Head Returns to Initial Position as Blade Motor and Coolant Stops.
The Vice will then Open (if there is another step, the step feeder will then begin to feed).
(REPEAT)
